Mode Field Adapter (PM or Non-PM) Mode Field Adapters (MFA) can be used for high power fiber lasers and fiber amplifiers. These devices can be used to connect two fibers with different core diameters and numerical apertures (NA).
工作温度：商业级/工业级/军品级可选
|
Mode Field Adapter (PM or Non-PM) |
||||||
|
|
|
|||||
|
Features |
Applications |
|||||
|
High Transfer Efficiency |
High Power Fiber Laser |
|||||
|
High Power |
Fiber Amplifier |
|||||
|
High Stability and Reliability |
|
|||||
|
Custom Configurations Available |
|
|||||
|
|
|
|||||
|
|
|
|||||
|
Specifications |
||||||
|
Parameters |
Value |
|||||
|
Port Configuration |
1×1 |
|||||
|
Signal Wavelength |
1030~1080nm or 1450~1600nm |
|||||
|
SMA Fiber |
6/125 |
10/125 |
10/125 |
6/125 |
20/250 |
|
|
LMA Fiber |
10/125 |
20/125 |
25/250 |
20/400 |
30/250 |
|
|
Signal IL for Forward Route |
0.3dB |
0.4dB |
0.5dB |
0.5dB |
0.2dB |
|
|
Signal IL for Backward Route |
0.3dB |
0.5dB |
0.7dB |
0.7dB |
0.2dB |
|
|
Total Handling Power |
Specify |
|||||
|
Polarization Extinction Ratio |
18dB (PM Fiber Type) |
|||||
|
Return Loss |
45dB |
|||||
|
Package Dimension |
D1, D2, D3, D4, D5, D6, D7 |
|||||
|
Operating Temperature |
-5~+70 |
|||||
|
Storage Temperature |
-40~+85 |
|||||
|
|
||||||
|
Ordering Information |
||||||
|
MFA–1-222–333-44-5-6-777 |
||||||
|
1 – Port Configuration: |
1=1x1 |
|||||
|
222 – Fiber Type for Input: |
SSS=Specify |
|||||
|
333 – Fiber Type for Output: |
SSS=Specify |
|||||
|
44 – Package Dimension: |
D1, D2, D3, D4, D5, D6, D7, SS=Specify |
|||||
|
5 – Pigtail Type: |
0=bare fiber, 1=900μm loose tube |
|||||
|
6 – Fiber Type: |
0.75=0.75m,1.0=1m, S=Specify |
|||||
|
777 – Handling Power/Signal: |
005=5W, 010=10W, 100=100W, 200=200W |
|||||
Notes:
- Package dimensions: D1=φ4.0x60mm, D2=50x5x5mm, D3=70x12x8mm, D4=75x12x8mm, D5=80x14x10mm, D6=100x15x10mm, D7=100x28x12.6mm-HP；
Pleased to contact us if you need more fiber selections；
Part No. Example: MFA-SSS-SSS-D3-0-0.75-010
Description: Mode Field Adapter, 1×1， Fiber Type for Input: Specify, Fiber Type for Output: Specify, 70x12x8mm,
bare fiber, 0.75m fiber length, 10W.
For Custom Parts, please provide detailed description for your requirement.
