产品特点 / Features
- 超紧凑 4CH仅20×12×6.5mm
- 1260-1360nm 波长范围(LAN波段)
- CW±1.1nm 通带宽
- 极低IL 4CH <1.2dB,8CH <1.8dB
- 相邻隔离度 >30dB,非相邻 >40dB
- 工作温度 -40~+85℃
- 250μm Corning ClearCurve光纤
- RoHS 合规
典型应用 / Applications
- 集成到 CFP/CFP2 光收发器
- 局域网(LAN)应用
- 高速收发器波分集成
- 数据中心互联
规格参数 / Specifications
| 参数 | 4通道 | 6通道 | 8通道 | 12通道 | 单位 |
|---|---|---|---|---|---|
| 波长范围 | 1260-1360 | 1260-1360 | 1260-1360 | 1260-1360 | nm |
| 通带 | ±1.1 | ±1.1 | ±1.1 | ±1.1 | nm |
| 插入损耗 | <1.2 | <1.5 | <1.8 | <2.0 | dB |
| 通道平坦度 | ≤0.5 | ≤0.5 | ≤0.5 | ≤0.5 | dB |
| 隔离度-相邻 | >30 | >30 | >30 | >30 | dB |
| 隔离度-非相邻 | >40 | >40 | >40 | >40 | dB |
| 偏振损耗 | <0.5 | <0.5 | <0.5 | <0.5 | dB |
| 工作温度 | -40~+85 | -40~+85 | -40~+85 | -40~+85 | ℃ |
| 尺寸4CH | 20×12×6.5 | mm | |||
| 尺寸6/8CH | 23×12.4×6.5 | 23×12.4×6.5 | mm | ||
| 尺寸12CH | 25×19.6×6.5 | mm |
本产品为【(C05)北亿纤通全品类波分复用器选型手册_V3.04.pdf】光模块产品线,详细信息请联系我们的销售人员,谢谢!
Important Notice
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
