Product Specifications
| Parameter | Value |
|---|---|
| Part Number | FT-S29-ATO19-D2S01 |
| Product Type | SFP+ 2X1 Cage+Connector |
| Cage Material | Copper Alloy, 30μ” Min Ni-Plated, Thickness 0.25mm |
| Connector Housing | High Temperature LCP, UL94V-0 |
| Light Pipe | Polycarbonate, Color: Clear |
| Spring | Stainless Steel, Thickness 0.20mm |
| Contacts | Phosphor Bronze, Thickness 0.20mm |
| Plating | 15μ” Min. Gold on Mating Area, 150μ” Min. Mate Tin on Solder Tails |
| Packaging | Tray Packaging |
| Operating Temperature | -40°C to +85°C |
| Storage Temperature | -55°C to +105°C |
| Scale | 1:1 |
| Unit | mm |
| Revision | A |
Contact Information
Company: 北亿纤通 | F-tone Networks
Region: 中国四川天府新区
Service Area: Global
Tel: 028-85255257 | Fax: 028-85977702 | Mobile: 19081343401
Site: https://www.f-tone.com
HR: hr@f-tone.com | Sales: sales@f-tone.com | Support: support@f-tone.com
本产品为【SFP+ Cage & Connector】产品线，详细信息，请联系我们的销售人员，谢谢！
Important Notice
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice. The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
