FT-161077-00631 QSFP112 1×2-PF-C05 W-HS Cage Assembly
The FT-161077-00631 is a QSFP112 1×2-PF-C05 W-HS cage assembly for high-speed optical transceiver modules. Features stainless steel cage and clip construction with integrated heat sink and EMI springs for reliable performance.
Specifications
| Parameter | Value |
|---|---|
| Material | Stainless Steel, Thickness |
| Clip | Stainless Steel |
| EMI Springs | Thickness 0.08mm |
| Heat Sink | Aluminum |
| Design | Andy |
| Part No | FT-161077-00631 |
| Rev | A1 |
本产品为SFP Cage & Connector产品线，详细信息，请联系我们的销售人员，谢谢！
Important Notice
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice. The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
