FT-79-OM-TSC131NC-OST1 S-Mini Analog Optical Transmitter


S-Mini Analog Optical Transmitter with Pigtail

FT-79-OM-TSC131NC-OST1

Features

◆Supper-Mini size :31.3mm*17mm*10mm(L*W*H)

◆Un-cooled(without TEC),low power consumption

◆CWDM wavelength optional

◆Wide operating frequency from 10MHz to 6GHz

◆Flat frequency response

◆Single +5V Power supply

◆Have optical power monitoring function

◆Automatic optical power control(APC)

◆Broadbandlownoiseamplifier(LNA)integrated(optional)

◆Bias-T circuit integrated for power supply through the RF SMA connector

(optional,see the schematic diagram below)

◆RoHS compliant and CE certification

◆Excellent EMI/EMC design

Applications

◆WiMAX / 4G / 5G

◆Satellite communications

◆Mobile backhaul

◆GPS signal transport

◆All-Digital QAM network

Bias-T Schematic Diagram

◆Data and video distribution

◆Distributed antenna system

V 3.06

1 /6

Absolute Maximum Ratings

Parameter Symbol Condition Min. Max. Unit

Operating Case Temperature Topr -20 +70 °C

Storage Temperature Tstg -40 +85 °C

DC Operating Voltage Vd +5VPin +4.7 +5.5 V

Without LNA — 20

RF Input Power Prf dBm

With LNA — 15

Output Optical Power Ps CW — 12 mW

Relative Humidity Hr — 95 %

Pressure Pr 86 106 kPa

ESD Human body model Class 1A

Note:Operation beyond these absolute maximum conditions may degrade device performance, lead to device failure, shorter

lifetime, and will invalidate the device warranty.

Typical Specification(1)

Parameter Test Condition MIN TYP MAX Unit

. .

TSC 0.01 ~ 3

Frequency Range(1) GHz

TCC 0.01 ~ 6

Optical Wavelength CWDM optional nm

Tx with LNA

6 14 —

Rx with LNA

Tx with LNA

-11 -3 —

Rx without LNA

TSC

Tx without LNA

-11 -3 —

Rx with LNA

Gain(2) dB

Tx without LNA

-28 -24 —

Rx without LNA

Tx without LNA

-11 -3 —

Rx with LNA

TCC

Tx without LNA

-30 -26 —

Rx without LNA

100M~3GHz,1270nm~1370nm — ±1.5 ±2.2

TSC

100M~3GHz,1530nm and 1550nm — ±2.5 ±3.0

Ripple of Passband dB

100M~6GHz,1270nm~1370nm — ±1.5 ±2.2

TCC

100M~6GHz,1530nm and 1550nm — ±2.5 ±3.0

Output Optical Power +25℃ — 9 — dBm

V 3.06

2 /6

Parameter Condition Min. Max. Unit
Symbol
Operating Case Temperature Topr -20 +70 °C
Storage Temperature Tstg -40 +85 °C
DC Operating Voltage Vd +5VPin +4.7 +5.5 V
RF Input Power Prf Without LNA
With LNA
20 dBm
15
Output Optical Power Ps CW 12 mW
Relative Humidity Hr 95 %
Pressure Pr 86 106 kPa
ESD Human body model Class 1A
Paramete r Te st Condition M IN TYP MAX Unit
Frequency Range(1) TSC
TCC
. .
0.01 ~ 3
GHz
0.01 ~ 6
Optical Wavelength CWDM nm
optional
Gain(2) TSC
TCC
Tx with LNA
Rx with LNA
6 14 dB
Rx with LNA
Tx with LNA -11 -3
-11 -3
Rx with LNA
Tx without LNA
Rx without LNA
-28 -24
Rx without LNA
Tx without LNA -11 -3
-30 -26
Rx without LNA
Ripple of Passband TSC
TCC
100M~3GHz,1270nm~1370nm ±1.5 ±2.2 dB
100M~3GHz,1270nm~1370nm
100M~3GHz,1530nm and 1550nm ±2.5 ±3.0
100M~3GHz,1530nm and 1550nm
100M~6GHz,1270nm~1370nm ±1.5 ±2.2
100M~6GHz,1270nm~1370nm
100M~6GHz,1530nm and 1550nm ±2.5 ±3.0
100M~6GHz,1530nm and 1550nm
Output Optical Power +25℃ 9 dBm
Rx without LNA
Tx without LNA
Rx with LNA
Tx without LNA

TSC 10MHz ~ 3GHz, RF Input — -10 -5

RF Return loss (50 Ω) dB

TCC 10MHz ~ 6GHz, RF Input — -10 -5

with LNA, 1.5GHz — 0 —

TSC

Input P-1dB(2) without LNA, 1.5GHz — 17 — dBm

TCC without LNA, 3GHz 17

TSC 1.5GHz 102 115 —

SFDR(2) dB·Hz2/3

TCC 3GHz 102 113 —

with LNA, 1.5GHz 4 9 —

TSC

Input IP3(2) without LNA, 1.5GHz 25 33 — dBm

TCC without LNA, 3GHz 21 33 —

with LNA, 1.5GHz

— 18 25

1270nm ~1370nm

with LNA, 1.5GHz

— 20 26

1530nm and 1550nm

TSC

without LNA, 1.5GHz

— 32 40

1270nm~1370nm

Noise Figure (2) dB

without LNA, 1.5GHz

— 35 42

1530nm and 1550nm

without LNA, 3GHz

— 32 42

1270nm ~1370nm

TCC

without LNA, 3GHz

— 38 45

1530nm and 1550nm

withLNA,TSC — 145 200

Operating Current mA

withoutLNA,TSC/TCC — 55 100

Operating Voltage +5V pin +4.8 +5 +5.2 VDC

Bias-T Voltage ThoughtheRFSMAconnector +4.8 +5 +5.2 VDC

Bias-T Current Supply Though the RF SMA connector – — 200 mA

S-Mini Optical Receiver (Rx)

Note:

(1) The lower start frequency such as kHz can be customized (without LNA only);

(2) Test with S-Mini optical receiver (see the picture below) and the fiber is 1-meter SMF-28 fiber.

V 3.06

3 /6

RF Return loss (50 Ω) TSC
TCC
10MHz ~ 3GHz, RF Input -10 -5 dB
10MHz ~ 6GHz, RF Input -10 -5
Input P-1dB(2) TSC
TCC
with LNA, 1.5GHz 0 dBm
without LNA, 1.5GHz 17
without LNA, 3GHz 17
SFDR(2) TSC
TCC
1.5GHz 102 115 dB·Hz2/3
3GHz 102 113
Input IP3(2) TSC
TCC
with LNA, 1.5GHz 4 9 dBm
without LNA, 1.5GHz 25 33
without LNA, 3GHz 21 33
Noise Figure (2) TSC
TCC
with LNA, 1.5GHz
1270nm ~1370nm
18 25 dB
with LNA, 1.5GHz
1530nm and 1550nm
20 26
without LNA, 1.5GHz
1270nm~1370nm
32 40
without LNA, 1.5GHz
1530nm and 1550nm
35 42
without LNA, 3GHz
1270nm ~1370nm
32 42
without LNA, 3GHz
1530nm and 1550nm
38 45
Operating Current withLNA,TSC
withoutLNA,TSC/TCC
145 200 mA
55 100
Operating Voltage +5V pin +4.8 +5 +5.2 VDC
Bias-T Voltage ThoughtheRFSMAconnector +4.8 +5 +5.2 VDC
Bias-T Current Supply Though the RF SMA connector 200 mA

Connector

Type Connector

RF SMA (50Ω), Female

Optical FC/APC (1)

Optical Fiber Type SMF-28(Standard)

Power EMI Low Pass Filter,FeedThrough Capacitor

Note (1): Other type optical connector available upon request.

PIN Function

PIN Name Direction Note

1 +5V Ⅰ +5V DC Power

2 GND Ⅰ RF and DC Ground

Optical Power Monitor,Power Level is +2.2V±0.4V Indicate Transmit Optical

3 OP O

Power Normal,Otherwise Indicate Transmit Optical Power Abnormal.

Optical Transmitter top view

Laser Safety and ESD Protection

1,The laser safety level of optical Tx modules is ClassⅢB (5mW~500mW). When using the Tx laser, the

user has to avoid to exposure to the beam.

2, The optical Tx modules have electrostatics sensitivity devices, so the user has to do a

good job of ESD protection when using the modules.

V 3.06

4 /6

Type Connector
RF SMA (50Ω), Female
Optical FC/APC (1)
Optical Fiber Type SMF-28(Standard)
Power EMI Low Pass Filter,FeedThrough Capacitor
PIN Name D irectio n Note
1 +5V +5V DC Power
2 GND RF and DC Ground
3 OP O Optical Power Monitor,Power Level is +2.2V±0.4V Indicate Transmit Optical
Power Normal,Otherwise Indicate Transmit Optical Power Abnormal.

Heat Dissipation Requirements:

In order to ensure proper performance, heat sinking and heat removal must be provided by the user to

limit maximum temperature of the transmitter and receiver module. The bottom of the module is the

preferred heat dissipation surface.

Mechanical (unit: mm)

Optical Transmitter

Note: When using the module, the bottom of the module needs to be fully cooled.

V 3.06

5 /6

Ordering Information

Optical Transmitter

FT-

79 – – TSC 131 N C – O S T 1

OM

Wavelength(2):

Frequency Range:TSC Optical Connector and Operating Temperature(4) Bias-T: LNA(5):

127:1270nm

:10M~3GHz

131: 1310nm

Fiber Type(3): S: -20 to 70℃ 1:without 0:without

TCC:10M~6GHz F:FC/APC SM T:with 1:with

129:1290nm …

L: LC/APC SM

137:1370nm

153:1530nm

155:1550nm

Note:(1) The lower start frequency such as 9kHz is available upon request (without LNA only) ;(2) Other wavelengths is

available upon request; (3) Other types of optical fiber connector type is available upon request; (4) Other temperature range

is available upon request, (5) LNA only supports TSC frequency band for the time being.

Important Notice

Performance figures, data and any illustrative material provided in this data sheet are

typical and must be specifically confirmed in writing by F-tone Networks before they

become applicable to any particular order or contract. In accordance with the F-tone

Networks policy of continuous improvement specifications may change without notice.

The publication of information in this data sheet does not imply freedom from patent or

other protective rights of F-tone Networks or others. Further details are available from any

F-tone Networks sales representative.

V 3.06

6 /6

FT-

79 –
OM
TSC 131 N C O S T 1
Frequency Range:TSC
:10M~3GHz
TCC:10M~6GHz
Wavelength(2)
127:1270nm
131: 1310nm
129:1290nm
137:1370nm
153:1530nm
155:1550nm

Optical Connector and
Fiber Type(3):
F:FC/APC SM
L: LC/APC SM
Operating Temperature(4)
S: -20 to 70℃
Bias-T:
1:without
T:with
LNA(5):
0:without
1:with
