Mellanox MFS1S50-H010E Compatible 10m (33ft) 200G HDR QSFP56 to 2x100G QSFP56 PAM4 Breakout Active Optical Cable

Mellanox — Mellanox MFS1S50-H010E Compatible 200Gb/s HDR to 2x100Gb/s HDR (QSFP56 to 2xQSFP56) Active Optical Splitter Cable with PAM4 modulation supports IBTA InfiniBand HDR.

Mellanox MFS1S50-H010E Compatible 10m (33ft) 200G HDR QSFP56 to 2x100G QSFP56 PAM4 Breakout Active Optical Cable
Mellanox MFS1S50-H010E Compatible 10m (33ft) 200G HDR QSFP56 to 2x100G QSFP56 PAM4 Breakout Active Optical Cable
Mellanox MFS1S50-H010E Compatible 10m (33ft) 200G HDR QSFP56 to 2x100G QSFP56 PAM4 Breakout Active Optical Cable

产品详情

产品参数 — F-tone
Mellanox Compatible MFS1S50-H010E 制造商名称 F-tone
封装 QSFP56 to 2x QSFP56 传输速率 212.5Gb/s
波长 850nm 线缆长度 10m (32.8ft)
调制技术 PAM4 设备要求 FEC
外护套材质 低烟无卤 最小弯曲半径 30mm
线缆类型 多模(MMF) 是否支持DDM Yes
发射激光器类型 850nm VCSEL 光接收器件类型 PIN
Operating Case Temperature 0 to 70°C (32 to 158°F) 电压 3.3V
协议 QSFP56 MSA, CMIS IEEE 802.3cd 200GBASE-SR4 最大功耗 < 5W (200G QSFP56), < 3W (100G QSFP56)
接口类型 Fiber Optic Cable 应用 200GBASE-SR4 to 2x 100GBASE-SR2 Ethernet, 200G InfiniBand HDR
Mellanox Compatible MFS1S50-H010E 制造商名称 F-tone
封装 QSFP56 to 2x QSFP56 传输速率 212.5Gb/s
波长 850nm 线缆长度 10m (32.8ft)
调制技术 PAM4 设备要求 FEC
外护套材质 低烟无卤 最小弯曲半径 30mm
线缆类型 多模(MMF) 是否支持DDM Yes
发射激光器类型 850nm VCSEL 光接收器件类型 PIN
Operating Case Temperature 0 to 70°C (32 to 158°F) 电压 3.3V
协议 QSFP56 MSA, CMIS
IEEE 802.3cd 200GBASE-SR4		 最大功耗 < 5W (200G QSFP56),
< 3W (100G QSFP56)
接口类型 Fiber Optic Cable 应用 200GBASE-SR4 to 2x 100GBASE-SR2 Ethernet, 200G InfiniBand HDR

v High-density QSFP56 MSA-compliant connectors

v 4 channels full-duplex active optical cables

v 4x uncooled 850nm VCSEL array and PIN photo-detector array (50G PAM4)

v Compliant with QSFP56 MSA, CMIS and IEEE 802.3cd 200GBASE-SR4

v Data rate up to 212.5Gbps

v Length up to 70m (OM3) or 100m (OM4/OM5) over MMF

v Power consumption < 5W (200G QSFP56), < 3W (100G QSFP56)

v 3.3V power supply voltage

v RoHS compliant (lead free)

v Application for 200GBASE-SR4 to 2x 100GBASE-SR2 Ethernet

Mellanox MFS1S50-H010E Compatible 10m 200G HDR QSFP56 to 2x100G QSFP56 Breakout Active Optical Cable (QSFP56 to QSFP56 AOC Breakout Cable, Active 10m)

200G QSFP56 to 2x 100G QSFP56 Breakout Active Optical Cable for 200G Ethernet links over OM3/OM4/OM5 multimode fiber via a 200G connector on one side and two separate 100GbE connectors on the other side Provides connectivity between system units. This cable connects data signals from 4 MMF (Multimode Fiber) pairs on a single QSFP56 end to dual pairs on each QSFP56 multiport end. This active optical splitter cable complies with QSFP-MSA and 200GBASE-SR4 specifications.

Quality Assurance

Excellent quality is the foundation of F-tone’ s survival and development. Our operation team are experts with many years’ experiences in optical communication industry. Our manufacturers are first-class manufacturers in the industry. Many of them have the qualification of OEM for first-class system equipment manufacturers.

Quality Certification

We control the quality of our products, including our strict qualification of manufacturers, quality control process and production technology, and compliance with certification and safety standards. At present, our products meet the industry standards and mainstream quality certification, such as ISO 9001, CE, RoHS, FCC, etc.

our advantages

Keep In Stock

Fast Delivery

Professional Service

Technical Support

Worry-Free Guarantee

Shopping Satisfactorily

Premium Quality

High stability

Rigorous Industrial ProductTesting

Optical communication products belong to industrial products,which require high stability and reliability.F-tone adopts leading product design, first-class raw materials and production technology to ensure the first-class quality of our products, so that your project can be used, installed stably and reliably

Temperature Impact

High and low temperature cycle,aging test to ensure good temperature characteristics

Mechanical Impact

Mechanicalvibration testing to ensure the stability of products

EMI Testing

Excellent designand rigorous testing ensuregood EMI performance

MTBF Testing

MTBF(Mean Time between Failures)testing ensure high stablility

100% 3rd Party Compatible

F-tone Compatibility Testing Center has most of the mainstream brand switches and devices.Before
shipment,We will code the optical modules or DAC/AOC cables,then test them on the corresponding switches to ensure that our products are 100% compatible with your system.

Coding(EEPROM Programming)
Testing system
本产品为北亿纤通产品线，详细信息，请联系我们的销售人员，谢谢！

Important Notice
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. rther details are available from any F-tone Networks sales representative.
