10GEPON-ONU-ASC Asymmetric 10GEPON ONU SFP+ TX-1.25G/RX-10.3G TX-1310nm/RX-1577nm PR30 SC DDM 0°C~70°C Optical Transceivers

10GEPON-ONU-ASC — F-tone 10GEPON-ONU-ASC Compatible 10G EPON Symmetrical PR30 ONU SFP+ Transceiver is designed for 10G EPON links on single-mode fiber up to 20km.

10GEPON-ONU-ASC Asymmetric 10GEPON ONU SFP+ TX-1.25G/RX-10.3G TX-1310nm/RX-1577nm PR30 SC DDM 0°C~70°C Optical Transceivers

产品详情

产品参数 — F-tone
F-tone型号 10GEPON-ONU-ASC 制造商名称 F-tone
应用 Asymmetric 10GEPON ONU ODN Class PRX30
波长 TX 1310nm/RX 1577nm 速率 TX 1.25G/RX 10.3G
发射光功率 +0.62~+5.62dBm 接收灵敏度 < -28.5dBm
包装 SFP+ 接口 SC
线缆类型 单模(SMF) 最远传输距离 20km
工作温度 0 to 70°C (32 to 158°F) 协议 IEEE 802.3av, SFP+ MSA
F-tone型号 10GEPON-ONU-ASC 制造商名称 F-tone
应用 Asymmetric 10GEPON ONU ODN Class PRX30
波长 TX 1310nm/RX 1577nm 速率 TX 1.25G/RX 10.3G
发射光功率 +0.62~+5.62dBm 接收灵敏度 < -28.5dBm
包装 SFP+ 接口 SC
线缆类型 单模(SMF) 最远传输距离 20km
工作温度 0 to 70°C (32 to 158°F) 协议 IEEE 802.3av, SFP+ MSA

v Single fiber bi-directional data links TX 10.3125Gbps, Burst Mode RX 10.3125Gbps application
v 3.3V, 5V power supply
v SFP+ package with SC Receptacle connector
v Hot-pluggable capability
v High power 1310nm DFB LD and high sensitivity APD
v Support 20km transmission distance with SMF
v CML-compatible data input/output interface
v Low power dissipation
v Low EMI and excellent ESD protection
v Digital diagnostic monitor interface
v RoHS6 compliance
Applications
v Asymmetric 10GEPON PRX30 ONU
Standards
v Complies with SFP+ MSA (SFF-8431)
v Complies with IEEE 802.3av
v Complies with FCC 47 CFR Part 15, Class B
v Complies with FDA 21 CFR 1040.10 and 1040.11, Class

Quality Assurance

Excellent quality is the foundation of F-tone’ s survival and development. Our operation team are experts with many years’ experiences in optical communication industry. Our manufacturers are first-class manufacturers in the industry. Many of them have the qualification of OEM for first-class system equipment manufacturers.

Quality Certification

We control the quality of our products, including our strict qualification of manufacturers, quality control process and production technology, and compliance with certification and safety standards. At present, our products meet the industry standards and mainstream quality certification, such as ISO 9001, CE, RoHS, FCC, etc.

our advantages

Keep In Stock

Fast Delivery

Professional Service

Technical Support

Worry-Free Guarantee

Shopping Satisfactorily

Premium Quality

High stability

Rigorous Industrial ProductTesting

Optical communication products belong to industrial products,which require high stability and reliability.F-tone adopts leading product design, first-class raw materials and production technology to ensure the first-class quality of our products, so that your project can be used, installed stably and reliably

Temperature Impact

High and low temperature cycle,aging test to ensure good temperature characteristics

Mechanical Impact

Mechanicalvibration testing to ensure the stability of products

EMI Testing

Excellent designand rigorous testing ensuregood EMI performance

MTBF Testing

MTBF(Mean Time between Failures)testing ensure high stablility

100% 3rd Party Compatible

F-tone Compatibility Testing Center has most of the mainstream brand switches and devices.Before
shipment,We will code the optical modules or DAC/AOC cables,then test them on the corresponding switches to ensure that our products are 100% compatible with your system.

Coding(EEPROM Programming)
Testing system


本产品为北亿纤通产品线，详细信息，请联系我们的销售人员，谢谢！

Important Notice
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. rther details are available from any F-tone Networks sales representative.
