FT-YRD05F 5-Port 10/100BASE-TX Industrial Ethernet Switch
Slim Type with more Practicability and Convenience
The FT-YRD05F is a hardened 5-port Industrial Ethernet Switch that provides non-blocking wire-speed performance in harsh industrial environments. It provides 5-port 10/100/100BASE-TX RJ45 copper interfaces delivered in an IP40 rugged, strong case with redundant power system. Its slim case is suitable for such applications as surveillance system deployments, control management and wireless service in climatically demanding environments with wide temperature range from -40°C to 85°C.
The FT-YRD05F series provides the flexibility to all kinds of 10/100Mbps Ethernet Media on RJ-45 port and performs highly stable fiber performance.
The FT-YRD05F series is packaged in a compact IP40 case that allows either DIN rail or panel mounting to have efficient usage of cabinet space. It provides an integrated power supply with a wide range of voltages for worldwide operation. It also offers dual-redundant, reversible polarity 12V DC to 52V DC power supply inputs for high availability applications requiring dual or backup power inputs.
Features
- Store and forward architecture
- 5 x 10/100Base-TX RJ45 ports
- IEEE 802.3, 802.3u, 802.3x compliant
- Full duplex flow control (back pressure for half duplex)
- Redundant dual power inputs (12-52V DC)
- IP40 aluminum housing, DIN-rail/panel mounting
- Wide operating temperature: -40°C to 85°C
- LED indicators for power and port status
Specifications
| Parameter | Value |
|---|---|
| Model | FT-YRD05F |
| Ports | 5 × 10/100BASE-TX RJ45 |
| Switching Capacity | 1.0 Gbps |
| MAC Address Table | 1K |
| Packet Buffer Memory | 96 Kbytes |
| Flow Control | Back pressure (half duplex), IEEE 802.3x (full duplex) |
| Enclosure | IP40 aluminum housing |
| Installation | DIN rail / Panel mounting |
| LED Indicators | Power: Red / Link/Activity: Green |
| Power Input | 12 to 52V DC redundant power |
| Power Consumption | <5W |
| Surge Protection | ±4KV |
| Certification | CE, FCC, RoHS |
| MTBF | >300,000 hours |
| Dimensions (W×D×H) | 105 × 83 × 36 mm |
| Weight | 0.35 kg (product) / 0.45 kg (packing) |
| Operating Temperature | -40°C ~ 85°C |
| Storage Temperature | -40°C ~ 85°C |
| Humidity | 5% ~ 95% (no condensation) |
| Warranty | 1-year replacement; 3-year main parts |
Ordering Information
| Model | Description |
|---|---|
| FT-YRD05F | 4-Port RJ45 + 1 Port RJ-45 uplink Industrial Switch, 100Mbps |
| FT-YZX5121-DC | DC 12V/1A power supply (non-PoE) |
| FT-YZX5241-DC | DC 24V/1A power supply (non-PoE) |
| FT-YZX5521-DC | DC 52V/1A power supply |
Company Information
Company: 北亿纤通 | F-tone Networks
Region: Tianfu New Area, Sichuan, China
Service Area: Global
Tel: 028-85255257 | Fax: 028-85977702 | Mobile: 19081343401
Website: https://www.f-tone.com
HR: hr@f-tone.com | Sales: sales@f-tone.com | Support: support@f-tone.com
本产品为【工业以太网交换机】产品线，详细信息，请联系我们的销售人员，谢谢！
Important Notice
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice. The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
